ZSM-5 Zeolite(MFI)

ZSM-5 Zeolite(MFI)

ZSM-5 Zeolite(MFI) belongs to MFI structure, is a white silica-rich synthesized
framework aluminosilicate with 0.55-0.60nm of channel window size. The zeolite
possess the adsorption to various molecules with high selectivity and high capacity,
and very high structure stability, which can be used to make high efficient selective
catalysts and adsorbents,and carrier of catalysts.

Catalyst in the process of petrol-chemistry and fine chemistry;
Activator in FCC catalyst for improving octane level of gasoline and increasing the yield of propylene and ethylene;
Catalyst in the process of petrol-chemistry and fine chemistry;
Catalysts for reduce pour point of diesel and lube oil;
Catalyst in petro-chemical and fine-chemical industry;
Adsorbents in treatment of waste water and exhaust gas;
Dehydration catalysts for alcohols;
Hydration catalyst of olefin;
Catalyst of cracking butylene;
Catalyst of cracking naphtha;
Hydrophobic adsorbent in environment protection;
Other catalysts needed in reaction with high solid acidity.

Request a Quote Get Datasheet

Characteristics and Advantages：

•  Regular crystal morphology

•  Excellent pore properties and large adsorption capacity

•  Good shape selectivity (for organic small molecules) and excellent adsorption and separation performance

•  Excellent thermal and hydrothermal stability of crystal structure

•  Extremely strong acid resistant chemical stability

•  Non toxic, harmless, safe and environmentally friendly

Packing: 10Kgs/15Kgs/20Kgs plastic woven bag

Specification of ZSM-5 Zeolite(MFI)

Product ItemSiO2/Al2O3 Na2O,(wt%)Powder FormBET Surface
area,m2/g		LOI(wt%)D50(v) µmRelative
Crystallinity %		Data Sheet
FYC-SMF-20n17-25≤0.05Aggregates of nano-crystals≥350≤5≤5≥90
FYC-SMF-30n25-35≤0.05Aggregates of nano-crystals≥350≤5≤5≥90
FYC-SMF-40n30-45≤0.05Aggregates of nano-crystals≥350≤5≤10≥90
FYC-SMF-60n55-65≤0.05Aggregates of nano-crystals≥350≤5≤10≥90
FYC-SMF-150s120-180≤0.05Singal CrystalsRod form≥350≤5≤10≥90
FYC-SMF-300s250-350≤0.05Singal CrystalsRod form ≥350≤5≤10≥90
FYC-SMF-400s350-450≤0.05Singal CrystalsRod form ≥350≤5≤10≥90
FYC-SMF-600s500-700≤0.05Singal CrystalsRod form≥350≤5≤10≥90
FYC-SMF-1000s>900≤0.05Singal CrystalsRod form≥350≤5≤15≥90
FYC-SMF-1500s≥1500≤0.05Singal CrystalsRod form ≥350≤5≤15≥90
